Godox X3PRO-C Wireless Flash Trigger for Canon User Manual

1. Wprowadzenie

The Godox X3PRO-C is a wireless flash trigger designed for Canon cameras, offering advanced control over your flash units. It features a 2.4-inch color touchscreen, integrated Bluetooth for app control, and utilizes the Godox 2.4G Wireless X System for reliable communication. This manual will guide you through the setup, operation, and maintenance of your X3PRO-C to ensure optimal performance.

2. Główne cechy

• 2.4-inch Full-color Touchscreen: Provides an intuitive interface for real-time monitoring and adjustment of up to 16 lighting groups.
• Bluetooth Integration & App Control: Seamlessly connects to the Godox Flash App for remote control of flash groups, power levels, and triggering via smart devices.
• Professional Shooting Modes: Includes One-Shoot for single setups, All-Shoot for group sessions, and L-858 Mode for precise meter-based control with Sekonic L-858 light meters.
• Godox 2.4GHz Wireless X System: Offers a wide transmission range, interference-resistant channel scanning, supporting up to 16 groups, 32 channels, and 99 wireless IDs.
• Precise Group Control: Allows independent adjustment of TCM (TTL Convert Manual), Zoom Value, and Modeling Lamp for each lighting group.
• Fast Charging, Long Runtime: Equipped with a built-in lithium battery providing up to one month of standby time and a 2-hour full recharge via USB-C.
• Kompaktowa i trwała konstrukcja: Lightweight and portable for on-location shoots, maintaining industrial-grade durability.

3. Co znajduje się w pudełku

The Godox X3PRO-C package typically includes the following items:

• Flash Trigger (X1)
• Case (X1)
• USB Type-C Charging Cable (X1)
• Lens Cloth (X1)

4. Konfiguracja

4.1 Ładowanie akumulatora

Before first use, fully charge the built-in lithium battery. Connect the provided USB Type-C cable to the trigger's USB-C port and a compatible USB power source. A full charge typically takes approximately two hours. The battery indicator on the screen will show charging status.

4.2 Montaż na kamerze

Slide the X3PRO-C onto your Canon camera's hot shoe until it clicks into place. Ensure it is securely fastened to prevent accidental detachment during use.

4.3 Włączanie/wyłączanie

Press and hold the power button located on the side of the trigger to turn it on or off. The touchscreen will illuminate upon activation.

4.4 Pairing with Flash Units (2.4G Wireless X System)

To control Godox flash units, ensure they are set to the same 2.4G wireless channel and group as the X3PRO-C. Use the touchscreen interface to set the channel (CH), group (GR), and wireless ID (ID) on the X3PRO-C to match your flash units. Refer to your flash unit's manual for specific pairing instructions.

The 2.4G Wireless X System allows for stable and efficient control of multiple flash units, even in complex lighting setups. It supports up to 16 groups, 32 channels, and 99 wireless IDs to minimize interference.

4.5 Connecting to Godox Flash App (Bluetooth)

Download the Godox Flash App from your device's app store. Enable Bluetooth on your smartphone or tablet and on the X3PRO-C. Open the app and follow the on-screen instructions to pair with your X3PRO-C. The default Bluetooth access code is 000000. This enables remote control of flash settings.

5. Instrukcja obsługi

5.1 Interfejs dotykowy

The 2.4-inch color touchscreen displays up to four lighting groups simultaneously. Tap on a group to adjust its parameters. Use the rotary dial for fine adjustments. The intuitive interface allows for quick switching between TTL and Manual modes, and precise control over power, zoom, and modeling lamp Ustawienia.

5.2 Adjusting Flash Parameters

• Moc wyjściowa: Tap a group and use the dial or on-screen controls to adjust flash power.
• Wartość powiększenia: Adjust the flash zoom to match your lens focal length for optimal light spread.
• Modelowanie Lamp: Kontroluj modelowanie lamp on compatible flash units for previewefekty świetlne.
• Funkcja TCM: Convert TTL settings to manual power levels for consistent results.

The X3PRO-C allows for independent adjustment of each lighting group, enabling precise control over your lighting setup. You can save and instantly recall complex settings using the preset function.

5.3 Professional Shooting Modes

The X3PRO-C offers three distinct shooting modes:

• One-Shoot Mode: Transmits only trigger signals, ideal for single-shooter setups to conserve battery.
• All-Shoot Mode: Transmits both settings and trigger signals simultaneously, suitable for group photography or multi-photographer teams.
• Tryb L-858: Connects with a Sekonic L-858 light meter, synchronizing meter readings to the flash for precise exposure control.

5.4 Kreatywne sterowanie migawką

Program single-shot, time-lapse, and long-exposure sequences directly through the intuitive touchscreen. Customize exposure duration, intervals, and shot count. The trigger can also be used via the PC sync port or with Godox XR/TR-RX receivers to minimize camera body vibration during these sequences.

6. Konserwacja

• Czyszczenie: Use a soft, dry cloth to clean the exterior of the trigger. For the touchscreen, use the provided lens cloth or a microfiber cloth. Avoid using harsh chemicals or abrasive materials.
• Składowanie: Store the X3PRO-C in a cool, dry place, away from direct sunlight and extreme temperatures. Use the provided case for protection during transport.
• Pielęgnacja baterii: To prolong battery life, avoid fully discharging the battery frequently. If storing for extended periods, charge the battery to approximately 50% and recharge every few months.
• Aktualizacje oprogramowania układowego: Check the official Godox webOdwiedzaj tę witrynę okresowo w celu uzyskania aktualizacji oprogramowania sprzętowego, aby zapewnić optymalną wydajność i dostęp do nowych funkcji.

7. Rozwiązywanie Problemów

• Wyzwalacz nie włącza się: Ensure the battery is charged. Connect to a USB-C power source and try again.
• Flash units not firing:
  • Verify that the X3PRO-C and flash units are on the same 2.4G wireless channel and group.
  • Check that the wireless ID settings match.
  • Ensure flash units are powered on and ready to fire.
  • Confirm the X3PRO-C is securely mounted on the camera's hot shoe.
• Problemy z połączeniem Bluetooth:
  • Ensure Bluetooth is enabled on both the X3PRO-C and your smart device.
  • Uruchom ponownie oba urządzenia.
  • Forget the device in your smart device's Bluetooth settings and re-pair.
  • Confirm the Godox Flash App is up to date.
• Ekran dotykowy nie reaguje: Uruchom ponownie urządzenie. Jeśli problem będzie się powtarzał, skontaktuj się z obsługą klienta.

8. Specyfikacje

9. Gwarancja i wsparcie

Godox products are manufactured to high-quality standards. For specific warranty information, please refer to the warranty card included with your product or visit the official Godox website. If you encounter any issues or require technical assistance, please contact Godox customer support or your authorized dealer. Keep your purchase receipt as proof of purchase for warranty claims.
