OLIGHT Perun 3 Mini Premium Headlamp Instrukcja obsługi

Wstęp

OLIGHT Perun 3 Mini Premium Headlamp is a compact and powerful lighting solution designed for versatility and convenience. It features dual light sources, including white and red light modes, and comes with a portable charging case that extends its runtime significantly. This manual provides detailed instructions for the proper use, maintenance, and troubleshooting of your Perun 3 Mini.

OLIGHT Perun 3 Mini Premium Headlamp, shown with its adjustable headband and the included charging case. The headlamp itself is detachable and can be used as a compact flashlight.

Główne cechy:

• Kompaktowy i mocny: Delivers up to 1,250 lumens with a 155-meter beam distance.
• Wydłużony czas działania: Charging case recharges the Perun 3 Mini up to five times, providing up to 60 days of runtime.
• Podwójne źródła światła: Features 5 white light modes and 3 red light modes for various scenarios.
• Bezproblemowa kontrola: Operate and adjust brightness directly through the case's display button.
• Wszechstronne ładowanie: USB-C port on the case allows charging of the headlamp i innych urządzeń mobilnych.
• Accurate Battery Monitoring: Digital display button provides precise battery level readings.

Co jest w pudełku

Upon opening your OLIGHT Perun 3 Mini Premium Headlamp package, please ensure all the following components are present:

• Perun 3 Mini (Battery and Pocket Clip Included)
• Etui ładujące Perun 3 Mini
• Kabel ładujący USB
• Opaska i uchwyt
• Ściereczka do czyszczenia

All items included in the OLIGHT Perun 3 Mini Premium Headlamp pakiet.

Organizować coś

Attaching the Headlamp to the Headband:

1. Locate the headband and the bracket.
2. Align the Perun 3 Mini with the bracket on the headband.
3. Gently push the headlamp into the bracket until it clicks securely into place. Ensure the light is facing forward.
4. Dopasuj opaskę tak, aby wygodnie i stabilnie przylegała do głowy.

Naczelnyamp easily detaches from and attaches to the headband bracket with a simple push mechanism.

Początkowe ładowanie:

Before first use, it is recommended to fully charge both the Perun 3 Mini and its charging case.

1. Place the Perun 3 Mini into its charging case.
2. Connect the USB Charging Cable to the USB-C port on the charging case.
3. Podłącz drugi koniec kabla USB do kompatybilnego źródła zasilania USB (np. zasilacza sieciowego, portu USB komputera).
4. The digital display on the case will indicate the charging status. A full charge is indicated when the display shows 100%.

The charging case not only recharges the Perun 3 Mini but can also charge other USB-C devices like smartphones.

Instrukcja obsługi

Basic Operation (via Charging Case):

The Perun 3 Mini can be operated directly through the display button on its charging case without needing to remove the light.

• Włączanie/wyłączanie: Press the display button once to turn the light on or off.
• Regulacja jasności (płynne przyciemnianie): When the light is on, press and hold the display button to cycle through brightness levels. Release the button at your desired brightness.
• Przełączanie trybu: Double-press the display button to switch between white light and red light modes.

Control the Perun 3 Mini directly from the charging case using the display button for quick adjustments.

Tryby oświetlenia:

The Perun 3 Mini offers various white and red light modes to suit different needs.

• Białe światło: Ideal for general illumination, working, hiking, and camping. Features multiple brightness levels.
• Czerwone światło: Preserves night vision, useful for signaling, or when minimal light is required. Includes an SOS mode for emergencies.

The Perun 3 Mini offers both bright white light for general use and a red light option for preserving night vision or signaling.

Monitorowanie stanu baterii:

The digital display on the charging case provides real-time battery level information.

Monitor the battery level of your charging case and the docked headlamp with the clear LED digital display.

Wszechstronne zastosowanie:

Beyond being a headlamp, the Perun 3 Mini can be used in various configurations:

• Podstawa magnetyczna: The magnetic tail cap allows attachment to metal surfaces for hands-free lighting.
• Klip kieszonkowy: Use the included pocket clip to attach the light to clothing, backpacks, or belts.
• Wiszące: The design allows for hanging the light, ideal for tent lighting or overhead illumination.

The Perun 3 Mini offers multiple carrying and mounting options, including magnetic attachment, clipping, and hanging.

Konserwacja

• Czyszczenie: Use the provided cleaning cloth or a soft, dry cloth to wipe the lens and body of the headlamp. Unikaj stosowania agresywnych środków chemicznych i materiałów ściernych.
• Port ładowania: Keep the USB-C charging port on the case free from dust and debris to ensure proper charging.
• Składowanie: Store the Perun 3 Mini and its charging case in a cool, dry place when not in use. For long-term storage, ensure the battery is partially charged (around 50%) to prolong battery life.
• Wodoodporność: The Perun 3 Mini is IPX8 rated, meaning it is submersible up to 2 meters for 30 minutes. However, avoid prolonged submersion and ensure the charging port is dry before charging.

Rozwiązywanie problemów

• Światło nie włącza się:
  • Upewnij się, że nagłówekamp is properly seated in the charging case if operating via the case button.
  • Check the battery level on the charging case display. Recharge if necessary.
  • If using the headlamp independently, ensure it is charged.
• Problemy z ładowaniem:
  • Sprawdź, czy kabel USB-C jest prawidłowo podłączony do obudowy i źródła zasilania.
  • Wypróbuj inny kabel USB-C lub zasilacz.
  • Ensure the charging port is clean and free of obstructions.
• Słaby strumień świetlny:
  • Bateria może być słaba. Naładuj urządzenie.
  • Upewnij się, że obiektyw jest czysty.

If you encounter issues not covered here, please refer to the Warranty and Support section for assistance.

Specyfikacje

Comprehensive output specifications for the Perun 3 Mini's white and red light modes, along with charging case specifications.

The Perun 3 Mini is built to endure, featuring IPX8 water resistance and 1.5-meter drop resistance.

Gwarancja i wsparcie

OLIGHT stands behind the quality of its products. The OLIGHT Perun 3 Mini Premium Headlamp jest dostarczany z Dożywotnia gwarancja, ensuring long-term reliability and customer satisfaction.

For warranty claims, technical support, or any inquiries regarding your product, please visit the official OLIGHT webOdwiedź stronę internetową lub skontaktuj się bezpośrednio z działem obsługi klienta. Zachowaj paragon jako dowód zakupu.

OLIGHT's commitment to quality is backed by a lifetime warranty and extensive industry experience.
