LEADZM Piano209 88-klawiszowe pianino cyfrowe z pełnym ważeniem – instrukcja obsługi

1. Wprowadzenie

Thank you for choosing the LEADZM Piano209 Digital Piano. This instrument combines the authentic feel of an acoustic piano with modern digital features, including a fully weighted 88-key hammer action keyboard, a high-quality DREAM sound source, and versatile connectivity options like MIDI and Bluetooth audio. This manual provides essential information for setup, operation, and maintenance to ensure optimal performance and longevity of your digital piano.

2. Co znajduje się w pudełku

Sprawdź, czy w przesyłce znajdują się wszystkie wymienione poniżej elementy:

• 1 x LEADZM Digital Piano
• 1 x zasilacz
• 1 x Triple Pedal Unit
• 1 x słuchawki
• 1 x Headphone Adapter
• 1 x kabel USB
• 1 x Android Cable
• 1 x Piano Towel
• 1 x pokrowiec na pianino
• 1 x Keyboard Sticker Set
• 1 x Music Clip
• 1 x Screwdriver and Screw Accessories
• 1 x Instrukcja obsługi

If any items are missing or damaged, please contact LEADZM customer support.

3. Instrukcje konfiguracji

3.1 Rozpakowywanie i umieszczanie

1. Ostrożnie wyjąć wszystkie elementy z opakowania.
2. Place the digital piano on a stable, flat surface. Ensure adequate space around the instrument for comfortable playing and connections.
3. Avoid placing the piano in direct sunlight, near heat sources, or in areas with extreme temperature fluctuations or high humidity.

3.2 Montaż stojaka (jeśli dotyczy)

If your piano includes a stand, follow these general steps. Refer to the separate assembly diagram for detailed instructions and screw identification.

1. Identify all stand components and hardware (screws, bolts, etc.).
2. Assemble the side panels and crossbars using the provided screws. Ensure all connections are secure.
3. Carefully place the main piano unit onto the assembled stand, aligning the mounting holes.
4. Secure the piano to the stand using the appropriate screws. Do not overtighten.

Image: The LEADZM Piano209 Digital Piano fully assembled, showcasing its elegant design and integrated stand.

3.3 Connecting the Triple Pedal Unit

1. Locate the pedal input port on the underside or rear panel of the piano.
2. Connect the cable from the triple pedal unit firmly into the designated port.

Obraz: Zbliżenie view of the triple pedal system, showing the Soft, Sustain, and Sostenuto pedals.

3.4 Połączenie zasilania

1. Connect the power adapter to the DC IN jack on the piano.
2. Podłącz zasilacz do standardowego gniazdka elektrycznego.

4. Instrukcja obsługi

4.1 Włączanie/wyłączanie zasilania

• Aby włączyć, naciśnij MOC przycisk znajdujący się na panelu sterowania.
• Aby wyłączyć, naciśnij i przytrzymaj MOC przycisk, aż wyświetlacz się wyłączy.

Image: The simple control panel of the LEADZM Digital Piano, featuring power, volume, and function buttons.

4.2 Funkcje klawiatury

• 88 Fully Weighted Keys: The hammer action keyboard provides a realistic piano feel, with heavier touch in the lower register and lighter touch in the higher register.
• Sterowanie dotykowe: Adjust the keyboard's sensitivity to your playing style. This allows for dynamic expression, from soft to powerful tones.
• Split Function: Divide the keyboard into two sections, allowing two different voices to be played simultaneously.
• Transponować: Shift the pitch of the entire keyboard up or down in semitone steps without changing your fingerings.

Image: Illustration of the fully weighted keyboard and its touch response, showing how key force affects sound dynamics.

4.3 Sound and Rhythm Selection

The Piano209 features a high-quality DREAM sound source with a wide array of musical options:

• 128 Tones (Voices): Select from various instrument sounds, including grand pianos, electric pianos, organs, strings, and more. Use the TON button to cycle through or select specific tones.
• 128 rytmy: Choose from a selection of accompaniment rhythms to practice with. Use the RYTM przycisk, aby wybrać.
• 20 utwory demonstracyjne: Enjoy pre-recorded demonstration songs. Press the DEMONSTRACJA przycisk, aby rozpocząć odtwarzanie.
• Metronom: Activate the metronome for timing practice.

4.4 Funkcje pedałów

The triple pedal unit provides enhanced expressive control:

• Miękki pedał (lewy): Reduces the volume and slightly alters the timbre of the notes played.
• Pedał sostenuto (środek): Sustains only the notes that are held down at the moment the pedal is pressed, allowing subsequent notes to be played without sustain.
• Pedał podtrzymujący (prawy): Sustains all notes played while the pedal is depressed, allowing them to ring out longer.

4.5 Funkcje łączności

• MIDI via USB: Connect the piano to a computer or tablet using a USB cable for MIDI interaction. This allows you to use the piano as a MIDI controller for music software (e.g., GarageBand) or to record your performances.

Image: A laptop connected to the digital piano via a USB cable, demonstrating MIDI functionality for music production software.

• Bluetooth Audio: The Bluetooth function automatically activates when the piano is powered on. You can connect your smartphone or tablet to the piano wirelessly to stream audio through the piano's speakers, allowing you to play along with your favorite songs or backing tracks.

Image: A smartphone displaying a music app, wirelessly connected to the digital piano via Bluetooth for audio streaming.

• Gniazdo słuchawkowe: Connect headphones to the 1/8" (3.5mm) headphone jack for private practice. Connecting headphones automatically mutes the internal speakers.

Image: Headphones plugged into the digital piano, illustrating the private practice feature.

• Nagrywanie/odtwarzanie: The piano includes a built-in sequencer for recording and playing back your performances. Refer to the control panel for specific record and playback buttons.
• AUX In/Out & Line In/Out: These ports allow connection to external audio devices, amplifiers, or recording equipment.

5. Konserwacja

Proper care will extend the life and performance of your digital piano:

• Czyszczenie: Use a soft, dry cloth (like the included piano towel) to wipe the surface of the piano. For stubborn dirt, slightly dampPrzetrzyj szmatkę wodą. Unikaj środków czyszczących o działaniu ściernym, rozpuszczalników i wosków, ponieważ mogą one uszkodzić wykończenie.
• Pielęgnacja klawiatury: Keep the keys clean. If necessary, wipe them gently with a slightly damp ściereczki. Nie stosować nadmiernej wilgoci.
• Składowanie: When not in use, cover the piano with the provided piano cover to protect it from dust and spills.
• Środowisko: Maintain a stable room temperature and humidity. Extreme changes can affect the instrument's components.
• Transport: When moving the piano, ensure it is properly disassembled from its stand (if applicable) and securely packed to prevent damage.

6. Rozwiązywanie Problemów

Jeśli napotkasz jakiekolwiek problemy, zapoznaj się z poniższymi typowymi problemami i ich rozwiązaniami:

If the problem persists after trying these solutions, please contact LEADZM customer support for further assistance.

7. Specyfikacje

8. Gwarancja i wsparcie

LEADZM is committed to providing high-quality products. For warranty information, please refer to the documentation included with your purchase or contact your retailer. For technical support, troubleshooting assistance, or inquiries about replacement parts, please visit the official LEADZM brand store or contact customer service through your point of purchase.

Więcej informacji i wsparcia znajdziesz na stronie LEADZM Brand Store.
