1. Koniec produktuview
The ESSAGER USB C to 3.5mm Audio Adapter is designed to connect your USB-C enabled devices, which lack a dedicated audio jack, to standard 3.5mm audio devices such as headphones, headsets, and speakers. It features an advanced DAC smart chip for high-fidelity sound and supports various control functions.
Image 1.1: The ESSAGER USB C to 3.5mm Audio Adapter, featuring a braided cable and metallic connectors.
Image 1.2: The adapter connected to a smartphone, illustrating its compact design and functionality.
2. Główne cechy
- Multi-Function Support: Connects USB-C devices to 3.5mm audio devices. Supports call management, volume control, and play/pause functions via wire control.
- Hi-Fi Sound Quality & Noise Reduction: Equipped with an advanced DAC smart chip for high-definition audio output and effective noise reduction, ensuring clear and detailed sound.
- Ekstremalna trwałość: Constructed with a premium aluminum alloy shell and a nylon-braided cable, designed to withstand over 20,000 bending tests for long-lasting use.
Image 2.1: Close-up of the adapter highlighting the integrated DAC smart chip for enhanced audio quality.
Image 2.2: Visual representation of the adapter's durable construction, including aluminum alloy shell and high-density braided thread.
3. Konfiguracja i obsługa
3.1. Plug and Play
The ESSAGER USB C to 3.5mm Audio Adapter is designed for immediate use without the need for drivers or additional software installation. Simply plug the adapter into your device's USB-C port and then connect your 3.5mm audio device to the adapter.
Image 3.1: The adapter connected to a laptop, demonstrating its plug-and-play functionality across various operating systems.
3.2. In-line Control
When using headphones or headsets with in-line controls, the adapter supports various functions directly through your audio device's buttons, including:
- Volume adjustment (increase/decrease)
- Odtwórz/wstrzymaj dźwięk
- Answer/Hang up calls (for Type-C devices)
Image 3.2: Illustration of the adapter's support for in-line controls, allowing convenient management of music and calls.
4. Szeroka kompatybilność
This USB C to 3.5mm audio adapter is compatible with a broad range of Type-C devices, including but not limited to:
- Smartfony: iPhone 16/15 series (Pro Max/Pro/Plus), Samsung Galaxy S24/S23/S22/S21/S20 series, Note 20/10/9/8, Pixel 9/8/7/6, Huawei Mate/P series, One Plus 6T/7/7Pro, and more.
- Tabletki: iPad Pro, iPad mini 6, and other Type-C tablets.
- Komputery: MacBooks, and other laptops with USB-C ports.
It supports TRRS and TRS audio jack types (OMTP/CTIA standards).
Image 4.1: A visual chart detailing the wide range of compatible devices and audio jack types supported by the adapter.
5. Rozwiązywanie Problemów
5.1. No Audio Output or Call Support
If your USB-C device already has a built-in 3.5mm audio port, this adapter may not support calling functions or may have limited audio output. This applies to certain models such as Galaxy S9/S8/Note 9/Note 8/S10, iPad Pro 11", and iPad Pro 12.9". For iPad Pro 2018, phone call and music control may not be supported.
Ensure the adapter is fully inserted into both the device's USB-C port and the 3.5mm audio device's jack.
5.2. Problemy z jakością dźwięku
If you experience static or poor sound quality, ensure that the audio source is of good quality and that the connections are secure. Test with different headphones or devices to isolate the issue.
6. Pielęgnacja i konserwacja
To ensure the longevity and optimal performance of your ESSAGER USB C to 3.5mm Audio Adapter, follow these guidelines:
- Avoid excessive bending or twisting of the cable, especially near the connectors.
- Utrzymuj adapter w czystości, bez kurzu i zanieczyszczeń. Do czyszczenia używaj miękkiej, suchej ściereczki.
- Przechowuj adapter w chłodnym i suchym miejscu, gdy nie jest używany.
- Do not expose the adapter to extreme temperatures or moisture.
7. Specyfikacje
| Atrybut | Szczegół |
|---|---|
| Marka | ESSAGER |
| Numer modelu | ESSAGER-USBC-3.5MM-AUX |
| Typ złącza | USB Type C (Male) to 3.5mm AUX (Female) |
| Tworzywo | Aluminum Alloy Shell, Nylon-Braided Cable |
| Układ DAC | Advanced DAC Smart Chip |
| Wymiary | 3.39 x 3.11 x 0.28 cala (opakowanie) |
| Waga przedmiotu | 0.634 uncji |
| Kolor | Szary |
Image 7.1: A visual representation of the adapter's dimensions and key specifications.
8. Wsparcie
For further assistance or inquiries regarding your ESSAGER USB C to 3.5mm Audio Adapter, please refer to the seller's contact information on the platform where the product was purchased. You may also visit the official ESSAGER brand store for additional product information and support resources.
Official ESSAGER Store: Sklep ESSAGER na Amazon
