Wstęp
This user manual provides comprehensive instructions for the installation, operation, and maintenance of your Agri-Cover Access 11339 Roll-up Tonneau Cover. Designed for durability and ease of use, this cover offers excellent protection for your truck bed cargo in various conditions. Please read this manual thoroughly before installation and use to ensure proper function and longevity of your product.
Informacje dotyczące bezpieczeństwa
- Always ensure the tonneau cover is securely latched before driving.
- Do not overload the cover or place heavy objects on top of it.
- Exercise caution when opening or closing the cover to avoid pinching fingers or hands.
- Keep children and pets away from the truck bed area during installation and operation.
- If any components are damaged, do not use the cover until repairs are made.
Zawartość opakowania
Przed rozpoczęciem instalacji należy sprawdzić, czy wszystkie komponenty są obecne:
- Access 11339 Roll-up Tonneau Cover Assembly
- 8 Tight Bite Clamps
- XT-Dial Tension Adjusters (pre-installed or separate)
- Premium Storage Straps
- Installation Hardware (bolts, washers, nuts, etc.)
- Instrukcja obsługi (ten dokument)
Konfiguracja i instalacja
Proper installation is crucial for the performance and longevity of your tonneau cover. It is recommended to have a second person assist with the installation process.
1. Prepare the Truck Bed
Ensure the truck bed rails are clean and free of debris. Remove any existing accessories that might interfere with the cover's installation.
2. Position the Cover Assembly
Carefully place the tonneau cover assembly onto the truck bed rails, ensuring it is centered and aligned with the tailgate. The front header bar should rest firmly against the bulkhead.
Image: The Access Roll-up Tonneau Cover shown fully installed and closed on a truck bed, providing a sleek, flat appearance.
3. Secure with Tight Bite Clamps
Attach the 8 Tight Bite clamps along the side rails of the truck bed, evenly spaced. Ensure the clamps are securely fastened to hold the cover firmly in place. Refer to the clamp manufacturer's instructions for specific torque settings if available.
4. Adjust Tension with XT-Dial
The XT-Dial tension adjusters allow you to fine-tune the tension of the cover fabric. Adjust these dials to achieve a taut, wrinkle-free surface. Proper tension ensures a tight weather seal and optimal performance.
Instrukcja wideo instalacji
Video: An official product video demonstrating the features and benefits of Access Roll-up Covers, including their style, function, and performance. This video provides a visual overview of how the cover operates and stores.
Instrukcja obsługi
Otwieranie pokrywy
To open the Access Roll-up Tonneau Cover, disengage the AutoLatch locking system located at the tailgate. Once disengaged, the cover can be easily rolled up towards the cab of the truck. The cover rolls open in seconds, providing full access to your truck bed.
Image: The tonneau cover shown in its rolled-up position near the truck's cab, secured by the premium storage straps, allowing full access to the truck bed.
Use the premium storage straps to secure the rolled-up cover near the cab, ensuring it stays completely out of the way for hauling larger items. This design allows for maximum bed utility.
Image: A woman sitting on the tailgate of a truck, demonstrating the full accessibility of the truck bed when the Access Roll-up Tonneau Cover is open and rolled up.
Zamykanie pokrywy
To close the cover, unroll it from the cab towards the tailgate. As you reach the tailgate, the AutoLatch system will automatically engage, securing the cover in place. Ensure both sides are properly latched for a secure fit and weather seal.
Konserwacja
- Czyszczenie: Clean the tonneau cover regularly with mild soap and water. Avoid harsh chemicals or abrasive cleaners that could damage the material. Rinse thoroughly and allow to air dry.
- Regulacja napięcia: Periodically check the tension of the cover using the XT-Dial adjusters. Adjust as needed to maintain a tight, wrinkle-free appearance and optimal weather protection.
- Clamp Kontrola: Inspect the Tight Bite clamps periodically to ensure they remain secure. Tighten if necessary.
- Uszczelnienie pogodowe: Check the Element Seal around the perimeter of the cover for any signs of wear or damage. A proper seal is essential for weather protection.
Rozwiązywanie problemów
| Problem | Możliwa przyczyna | Rozwiązanie |
|---|---|---|
| Cover appears loose or wrinkled. | Insufficient tension. | Adjust the XT-Dial tension adjusters to tighten the cover. |
| Water leaking into the truck bed. | Improper seal or loose clamps. | Ensure the Element Seal is properly seated. Check and tighten all 8 Tight Bite clamps. |
| Difficulty latching the cover. | Niewspółosiowość lub przeszkoda. | Verify the cover is centered and aligned. Check for any debris or obstructions preventing the AutoLatch from engaging. |
Specyfikacje
- Marka: Agri-Cover
- Model: 11339
- Styl: Roll-Up Tonneau Cover
- Tworzywo: Aluminum (frame/components), Fabric (cover)
- Typ zamka: AutoLatch (tailgate)
- Kod UPC: 834532009084
- Numer części OEM: 11339
Informacje o gwarancji
The Agri-Cover Access 11339 Roll-up Tonneau Cover is backed by a Premium Cover lifetime warranty. This warranty covers defects in materials and workmanship under normal use. For detailed warranty terms, conditions, and claim procedures, please refer to the official Agri-Cover warranty documentation or contact Agri-Cover customer support.
Wsparcie
For further assistance, technical support, or to inquire about replacement parts, please contact Agri-Cover customer service. You can typically find contact information on the manufacturer's official weblub za pośrednictwem sprzedawcy produktu.
