Wstęp
This manual provides detailed instructions for the proper use and maintenance of your Ming Yun X800 Remote Dog Training Remote. This remote control is designed to operate exclusively with the Ming Yun X800 Dog Training Receiver. Please read this manual thoroughly before use to ensure safe and effective operation.
Informacje dotyczące bezpieczeństwa
- This product is intended for use by adults aged 18 years and older.
- Always use the remote training system responsibly and humanely.
- Do not use this device on puppies under 6 months old or on dogs that are ill, pregnant, or have heart conditions.
- Ensure the receiver collar fits properly to avoid skin irritation.
- Consult a professional dog trainer if you are unsure about proper training techniques.
Zawartość opakowania
- Ming Yun X800 Remote Control
- 1 x AA Alkaline Battery (pre-installed or included separately)
- Instrukcja obsługi (ten dokument)
Organizować coś
Montaż baterii (pilot zdalnego sterowania)
The Ming Yun X800 Remote Control uses one AA Alkaline battery. If the battery is not pre-installed, open the battery compartment cover on the back of the remote and insert the AA battery, ensuring correct polarity. Close the cover securely.
Parowanie odbiornika
To ensure proper communication between the remote control and the receiver collar, they must be paired. Follow these steps:
- Włącz pilota: Switch the channel button on the remote to select the desired corresponding channel (1, 2, or 3).
- Prepare the receiver for pairing: Confirm that the receiver is off. Press and hold the receiver power button for 5 seconds. The green light on the receiver will begin to blink, indicating it is in pairing mode.
- Complete pairing: While the receiver's green light is blinking, press the beep button on the remote control. You will hear a beep sound, confirming that the pairing process is complete.
Obraz: This diagram illustrates the three steps for pairing the remote control with the receiver. Step 1 shows turning on the remote and selecting a channel. Step 2 shows pressing and holding the receiver's power button for 5 seconds until its green light blinks. Step 3 shows pressing the remote's beep button to complete the pairing.
Instrukcja obsługi
Once paired, your remote control is ready for use. The remote features buttons for various training functions:
- Przełącznik kanałów: Allows you to switch between different receiver collars if you are training multiple dogs (channels 1, 2, or 3).
- Przycisk dźwiękowy: Delivers an audible tone to the receiver collar.
- Przycisk wibracji: Delivers a vibration stimulus to the receiver collar.
- Static Stimulation Button: Delivers a static stimulation to the receiver collar.
- Przycisk światła: Activates a light on the receiver collar (if equipped).
Always start with the lowest stimulation level and gradually increase if necessary, observing your dog's reaction.
Konserwacja
- Czyszczenie: Przetrzyj pilota miękką, miękką szmatką.amp płótno. Nie używaj ostrych środków chemicznych ani ściernych środków czyszczących.
- Składowanie: Przechowuj pilota w chłodnym, suchym miejscu, z dala od bezpośredniego światła słonecznego i ekstremalnych temperatur.
- Bateria: If the remote will not be used for an extended period, remove the AA battery to prevent leakage.
Rozwiązywanie problemów
| Problem | Możliwa przyczyna | Rozwiązanie |
|---|---|---|
| Remote not turning on. | Rozładowana lub nieprawidłowo zainstalowana bateria. | Sprawdź biegunowość baterii lub wymień ją na nową baterię AA. |
| Remote not pairing with receiver. | Incorrect pairing procedure or receiver not in pairing mode. | Refer to the "Pairing the Receiver" section and repeat the steps carefully. Ensure the receiver's green light is blinking before pressing the beep button on the remote. |
| No response from receiver. | Receiver is off, out of range, or not charged (if applicable). | Ensure receiver is on and within operational range. Check receiver battery level. |
Specyfikacje
- Model: X800
- Marka: Ming Yun
- Kolor: Czarny
- Zgodne urządzenia: Ming Yun X800 Dog Training Receiver
- Typ baterii: 1 x bateria alkaliczna AA (w zestawie)
- Liczba jednostek: 1 Pilot zdalnego sterowania
- Kod UPC: 718819828547
- ASIN: B0F99J8CS1
Gwarancja i wsparcie
Aby uzyskać informacje o gwarancji lub pomocy technicznej, skontaktuj się bezpośrednio ze sprzedawcą lub producentem. Zachowaj paragon jako dowód zakupu.
