LMS-801

Masażer szyi i pleców Shiatsu

Model: LMS-801

Wstęp

Thank you for choosing the Shiatsu Neck and Back Massager. This device is designed to provide deep tissue kneading massage with optional soothing heat, helping to alleviate muscle soreness, ease stiffness, and promote relaxation. Please read this manual thoroughly before use to ensure safe and effective operation.

Informacje dotyczące bezpieczeństwa

Twoje bezpieczeństwo jest najważniejsze. Prosimy o przestrzeganie następujących środków ostrożności:

Cechy produktu

Zawartość opakowania

Shiatsu Neck and Back Massager with its retail box

Image: The Shiatsu Neck and Back Massager shown with its packaging box, illustrating the product's appearance and retail presentation.

Organizować coś

  1. Rozpakować: Ostrożnie wyjmij masażer i wszystkie akcesoria z opakowania.
  2. Podłączenie zasilania:
    • For home/office use, connect the AC power adapter to the massager's power input port, then plug the adapter into a standard electrical outlet.
    • For car use, connect the car power adapter to the massager's power input port, then plug the adapter into your vehicle's cigarette lighter socket.
  3. Bezpieczne połączenie: Ensure the power connector is pushed firmly into the massager's port. If the connection seems loose, apply a little more force to secure it.

Instrukcja obsługi

Familiarize yourself with the control panel buttons:

Close-up of the Smart Button control panel on the massager

Obraz: szczegółowy view of the control panel on the massager, highlighting the power button, two-way massage button, adjustable intensity button, and thermostat switch.

Kroki użytkowania:

  1. Podłącz masażer do źródła zasilania.
  2. Position the massager on the desired body area (neck, shoulders, back, legs, etc.). Use the long handle straps to adjust position and apply gentle pressure.
  3. Press the Power Button (⏻) to start the massage.
  4. Adjust the intensity using the Adjustable Intensity Button (≡).
  5. Turn the heat function ON or OFF with the Thermostat Switch (≈).
  6. The massager will automatically shut off after 15 minutes. You can restart it if desired, or manually turn it off by pressing the Power Button (⏻).
Various applications of the massager on different body parts

Image: Demonstrates the versatility of the massager, showing its use on the neck, upper back, lower back, thighs, and abdomen for full body relief.

People using the massager in different settings: office, car, and home

Image: Illustrates the portability and convenience of the massager, depicting individuals using it while working in an office, relaxing in a car, and at home on a couch.

Konserwacja

Proper care will extend the life of your massager:

Close-up of the massager's breathable mesh fabric and eco-friendly PU leather

Obraz: Zbliżenie view highlighting the breathable mesh fabric and eco-friendly PU leather materials used in the massager's construction, emphasizing its comfortable and durable design.

Rozwiązywanie problemów

ProblemMożliwa przyczynaRozwiązanie
Masażer się nie włącza.Nieprawidłowo podłączony do zasilania.Ensure the power adapter is securely plugged into both the massager and the power outlet/car socket. Push the connector firmly.
Masażer zatrzymuje się w trakcie użytkowania.Automatyczne wyłączanie zostało aktywowane.The massager has a 15-minute auto-shutoff feature. Wait a few moments and restart if desired.
Masaż wydaje mi się zbyt intensywny.Deep massage nodes.Place a towel or soft cloth between the massager and your body to reduce the intensity. Adjust the intensity level using the control panel.
Funkcja grzania nie działa.Funkcja grzania jest wyłączona.Press the Thermostat Switch (≈) to activate the heat function. Allow a few minutes for the heat to build up.

Specyfikacje

AtrybutSzczegół
Numer modeluLMS-801
Zasilacz110-240V, 60Hz (AC Adapter); 12V DC (Car Adapter)
Pobór mocy30 W
Wymiary produktu14.57 x 2.54 x 18.9 cale (w przybliżeniu)
Waga przedmiotu3.1 funta (w przybliżeniu)
TworzywoFaux Leather, Breathable Mesh Fabric
Węzły masujące8 (with 16 massage heads for two-way rotation)
Automatyczne wyłączanie15 minut
Kraj pochodzeniaChiny

Gwarancja i wsparcie

This product is manufactured by Shiatsu. For any product-related inquiries, technical support, or warranty claims, please refer to the contact information provided by your retailer or the manufacturer's official webStrona. Zachowaj dowód zakupu w celach gwarancyjnych.
