1. Koniec produktuview
The YU Xiang F07 UH-1 Huey RC Helicopter is a highly detailed 1:34 scale model designed for enthusiasts. It features advanced flight stability with a flybarless system, dual-axis brushless motors, and 6-axis electronic stabilization. This Ready-To-Fly (RTF) version includes all necessary components for immediate operation.
Image: The YU Xiang F07 UH-1 Huey RC Helicopter, showcasing its detailed design, alongside its remote control and battery. The packaging is also visible, indicating it's a RTF (Ready-To-Fly) kit.
Główne cechy:
- Authentic Scale Design: 1:34 scale UH-1 Huey model with lighting effects.
- Advanced Flight Stability: Flybarless system, dual-axis brushless motor, and 6-axis electronic stabilization.
- Mocne silniki bezszczotkowe: 1200KV main motor and 5500KV tail motor for responsive flight.
- Precyzyjna kontrola: High-torque 4.3g metal gear servos and wind-resistant stabilization.
- Beginner-Friendly Modes: 6G mode, altitude hold, optical flow sensors for stable hovering, and one-key inverted flight.
- Inteligentne funkcje bezpieczeństwa: Overcharge/discharge protection for the battery.
2. Zawartość opakowania
Sprawdź, czy w Twoim opakowaniu znajdują się wszystkie wymienione poniżej elementy:
- Aircraft (YU Xiang F07 UH-1 Huey RC Helicopter) x 1
- Instrukcja obsługi x 1
- Specialized USB charging cable x 1
- Main propeller blades x 4
- Tail propeller blades x 1
- Smart battery (7.4V 1200MAH) x 1
- Remote Control (2.4G) x 1
Image: The YU Xiang F07 UH-1 Huey RC Helicopter shown with its remote control, highlighting the main components included in the package.
3. Konfiguracja i przygotowanie
3.1 Ładowanie akumulatora
Before first use, fully charge the smart battery. Use only the specialized USB charging cable provided.
- Connect the USB charging cable to a USB power source (e.g., computer USB port, USB wall adapter).
- Podłącz akumulator do kabla ładującego.
- Kontrolka ładowania pokaże stan ładowania. Informacje na temat wskazań kontrolki znajdują się w instrukcji obsługi ładowarki.
- Czas pełnego naładowania wynosi około 60 minut.
Caution: Do not overcharge the battery. Disconnect once fully charged. Always supervise charging.
3.2 Instalowanie baterii
Insert the charged smart battery into the helicopter's battery compartment. Ensure it is securely seated to prevent disconnection during flight.
3.3 Przygotowanie pilota zdalnego sterowania
The remote control operates on a 2.4G frequency. Ensure it has sufficient power (batteries not specified in product description, assume user provides standard AA/AAA or it's rechargeable).
Image: Detailed diagram of the remote control, labeling its various buttons and joysticks, including Gas Pedal Unlock, Throttle lock, Boot Key, Throttle/Direction Rocker, Aileron/elevator rocker, Debug Pitch, One Touch Landing, Optical flow mode, Manual mode, and rudder volume buttons.
Zapoznaj się z układem pilota zdalnego sterowania:
- Gas Pedal Unlock / Throttle Lock: Controls motor arming and disarming.
- Throttle/Direction Rocker: Kontroluje wysokość i odchylenie.
- Aileron/Elevator Rocker: Kontroluje ruch do przodu/do tyłu oraz w lewo/w prawo.
- Optical Flow Mode / Manual Mode Dial: Switches between flight modes.
- Duży i mały przycisk głośności steru: Reguluje czułość steru.
- Boot Key: Zasilanie włącz / wyłącz.
- Debug Pitch / One Touch Landing: Advanced settings and automated landing.
The remote control supports ELRS protocol for corresponding receiver flight.
4. Instrukcja obsługi
4.1 Włączanie i parowanie
- Umieść helikopter na płaskiej, równej powierzchni.
- Turn on the helicopter's power switch.
- Turn on the remote control's power switch (Boot Key).
- The helicopter and remote control will automatically pair. Wait for the indicator lights to confirm successful pairing (refer to specific light patterns in the included manual).
4.2 tryby lotu
The F07 UH-1 Huey offers multiple flight modes for different skill levels:
- 6G Mode (Beginner-Friendly): Utilizes 6-axis gyro stabilization, altitude hold, and optical flow sensors for stable flight and pinpoint hovering. Ideal for new pilots.
- Tryb ręczny: Provides more direct control for experienced pilots.
Switch between modes using the Optical Flow Mode / Manual Mode dial on the remote control.
4.3 Podstawowe sterowanie lotem
Image: A visual representation of the helicopter's basic flight functions, including vertical movements (upwards, downwards) and horizontal movements (left flight, right flight, turn left, turn right, onward, backwards).
- Startować: Slowly push the Throttle/Direction Rocker upwards.
- Lądowanie: Slowly pull the Throttle/Direction Rocker downwards, or use the One Touch Landing function.
- Naprzód wstecz: Push the Aileron/Elevator Rocker forward or backward.
- Lot w lewo/prawo (Strafe): Push the Aileron/Elevator Rocker left or right.
- Skręć w lewo/prawo (odchylenie): Push the Throttle/Direction Rocker left or right.
- One-Key Inverted Flight: For advanced aerobatics, refer to the detailed manual for specific instructions on activating this feature.
The helicopter is designed for outdoor conditions, capable of handling up to Level 4-5 winds due to its wind-resistant stabilization and tail lock motor.
5. Konserwacja i pielęgnacja
Regular maintenance ensures the longevity and optimal performance of your helicopter.
- Czyszczenie: Wipe the helicopter with a soft, dry cloth after each use. Avoid using water or chemical cleaners.
- Kontrola śmigła: Regularly check main and tail propeller blades for any damage (cracks, bends). Replace damaged blades immediately using the provided spares.
- Pielęgnacja silnika: Ensure motors are free from dust and debris. Avoid prolonged operation in dusty environments.
- Przechowywanie baterii: Store the battery in a cool, dry place away from direct sunlight and extreme temperatures. For long-term storage, charge the battery to approximately 50% capacity.
- Kontrola serwa: Periodically check the movement of the 4.3g metal digital servos for smooth operation.
6. Rozwiązywanie Problemów
| Problem | Możliwa przyczyna | Rozwiązanie |
|---|---|---|
| Śmigłowiec nie reaguje na zdalne sterowanie. | Not paired; low battery in helicopter or remote; power switch off. | Ensure both are powered on. Re-pair the helicopter and remote. Charge helicopter battery. Replace remote control batteries. |
| Helicopter drifts or is unstable during flight. | Uncalibrated gyroscope; damaged propeller blades; strong wind. | Perform gyroscope calibration (refer to manual). Inspect and replace damaged blades. Fly in calmer conditions or use 6G mode. |
| Krótki czas lotu. | Akumulator nie jest w pełni naładowany; akumulator się starzeje. | Ensure battery is fully charged before each flight. Consider replacing the battery if it's old and capacity has degraded. |
| Silniki nie kręcą się. | Throttle not unlocked; motor damage. | Ensure throttle is unlocked using the Gas Pedal Unlock feature. If still no response, contact support. |
7. Specyfikacje produktu
| Funkcja | Szczegół |
|---|---|
| Model | F07 UH-1 Huey 6CH 6G Flybarless RC Helicopter Model |
| Średnica wirnika | 372mm |
| Długość kadłuba | 350mm |
| Wysokość | 122mm |
| Weight (Single Aircraft) | 228g |
| Silnik napędowy | 2511 1200KV brushless motor |
| Tail Lock Motor | 1204 5500KV brushless motor |
| Serwo | 4.3g metal digital servo |
| Zdalne sterowanie | Pilot 2.4G |
| Odległość zdalnego sterowania | Ponad 120 metrów |
| Bateria ciała | LI-POLY smart battery 7.4V (1200MAH) 25C |
| Rumak | Ładowarka USB |
| Czas ładowania | Około 60 minut |
| Czas lotu | 10-12 minut |
| Zalecany wiek | 16+ lata |
| Wymiary produktu | 38.5 x 37.5 x 12cm (Helicopter) |
| Kraj pochodzenia | Chiny |
Image: Diagram illustrating the dimensions of the YU Xiang F07 UH-1 Huey RC Helicopter, showing its length (375mm/14.76inch) and height (122mm/4.72inch).
8. Gwarancja i wsparcie
For warranty information, technical support, or replacement parts, please refer to the contact details provided with your purchase documentation or visit the manufacturer's official webZachowaj dowód zakupu na wypadek roszczeń gwarancyjnych.
This product is intended for users aged 16 and above.
