Wstęp
This manual provides comprehensive instructions for the Emerson 7" Portable TV LCD Monitor, Model ET-7000. It covers setup, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your device. Please read this manual thoroughly before using the product.
Image: The Emerson 7-inch Portable TV, showing the screen displaying a basketball game, along with its remote control and external antenna.
Co jest w pudełku
Po otwarciu opakowania należy sprawdzić, czy zawiera ono wszystkie poniższe elementy:
- Emerson 7" Portable TV
- Antena zewnętrzna
- Kabel A/V
- Zdalne sterowanie
- Instrukcja obsługi
- Podstawka
- Zasilacz sieciowy
- DC Car Power Cord
- Antenna Extension Adapter
Obraz: widok z góry view of all accessories and the portable TV laid out, including cables, adapters, remote, and stand.
Główne cechy
- Fully Loaded Features: Equipped with HDMI, USB, dual AV inputs, built-in speaker, full built-in digital tuner, headphone jack, Remote control and full-band digital TV tuner with ATSC & NTSC support.
- Trwały akumulator: Stay connected during power outages or on outdoor adventures. The built-in battery delivers hours of continuous play, plus it includes a 12V car charger for recharging anywhere.
Image: The portable TV plugged into a car's cigarette lighter socket, demonstrating the car charging capability.
Image: A man sitting on his luggage at an airport, smiling while holding and watching the portable TV, highlighting its portability.
- Wide Compatibility Across Devices: Stream and connect with HDMI, USB, AV, and more. Works with Roku, Amazon Firestick, Chromecast, DVD players, Slingbox, game consoles, Apple TV, laptops, and even security camera systems.
- Multi-purpose Display Functionality: Use it as a portable TV, computer monitor, gaming monitor, and more! Supports a variety of formats including MP3, MP4, MKV, WMV, FLV, AVI, H.264, HEVC(H.265), MPEG, MPEG 1, MPEG 2, MPEG 3, XVID, JPEG, RMVB, MKY, 3G, and more—ideal for movies, gaming, or professional use.
- Built for Travel & On-the-Go Use: Compact and lightweight with a fold-out stand, it's the perfect size for camping, RV trips, car rides, tailgating, or keeping kids entertained on the road, indoor & outdoor use.
Image: A woman enjoying a cup of coffee while watching the portable TV inside an RV, with a scenic view outside the window.
Image: A child sitting comfortably on a large, fluffy bean bag, holding and watching the portable TV, illustrating its use for kids.
Organizować coś
1. Włączanie
Connect the included AC power adapter to the DC 12V input port on the TV and plug it into a standard wall outlet. Alternatively, you can use the built-in rechargeable battery for portable use. Press the MOC button on the TV or remote control to turn the unit on.
2. Podłączenie anteny
For receiving over-the-air digital TV broadcasts, connect the external antenna to the ANTENA W port on the TV. Position the antenna for optimal reception. You may need to adjust its position during channel scanning or if signal quality is poor.
3. Początkowe skanowanie kanałów
After connecting the antenna and powering on the TV for the first time, it is recommended to perform an auto channel scan. Navigate to the MENU, wybierać KANAŁ or ORGANIZOWAĆ COŚ, a następnie wybierz AUTOMATYCZNE SKANOWANIE. The TV will search for available digital and analog channels in your area. This process may take several minutes.
Instrukcja obsługi
1. Podstawowe sterowanie
- Moc: Naciśnij MOC przycisk włączania i wyłączania telewizora.
- Tom: Użyj Objętość + I TOM- przyciski do regulacji poziomu głośności.
- Kanał: Użyj CH+ I CH- przyciski do zmiany kanałów.
- Niemy: Naciśnij NIEMY przycisk na pilocie, aby tymczasowo wyciszyć dźwięk.
2. Wybór wejścia
To switch between different video sources (e.g., TV tuner, HDMI, USB, AV), press the ŹRÓDŁO or WEJŚCIE button on the remote control or the TV. Use the arrow buttons to select your desired input and press OK.
3. Odtwarzanie multimediów (USB)
Włóż dysk flash USB do USB port. Select the USB input source. The TV's media player interface will appear, allowing you to browse and play compatible video, audio, and image filesą przechowywane na dysku USB.
Konserwacja
1. Czyszczenie
To clean the screen and casing, use a soft, dry cloth. For stubborn marks, slightly dampen the cloth with water or a mild, non-abrasive cleaner specifically designed for electronics. Avoid using harsh chemicals, solvents, or abrasive materials, as these can damage the surface.
2. Pielęgnacja baterii
To prolong the life of the built-in rechargeable battery, avoid fully discharging it frequently. Charge the battery regularly, even if the TV is not in constant use. Store the TV in a cool, dry place away from extreme temperatures.
Rozwiązywanie problemów
| Problem | Możliwa przyczyna | Rozwiązanie |
|---|---|---|
| Brak zasilania | Zasilacz nie jest podłączony; bateria jest rozładowana | Ensure AC adapter is securely plugged in; Charge the battery fully. |
| No signal / No channels | Antenna not connected or poorly positioned; No channel scan performed | Connect antenna securely; Adjust antenna position; Perform an auto channel scan. |
| Brak dźwięku | Volume too low; Mute function activated | Increase volume; Press the MUTE button on the remote. |
| Niska jakość obrazu | Weak signal; Antenna interference | Adjust antenna position; Try a different location for better reception. |
| Pilot nie działa | Baterie są rozładowane lub nieprawidłowo włożone; Przeszkoda między pilotem a telewizorem | Replace remote batteries; Ensure line of sight to the TV's IR sensor. |
Specyfikacje
Image: A diagram showing the dimensions of the portable TV: 8.1 inches (width), 4.6 inches (height), and 1.4 inches (depth), with a weight of 0.79 lbs.
| Funkcja | Szczegół |
|---|---|
| Nazwa marki | Emerson |
| Numer modelu | ET-7000 |
| Rozmiar ekranu | 7 cali |
| Technologia wyświetlania | LCD |
| Rezolucja | 720p |
| Częstotliwość odświeżania | 60 Hz |
| Proporcje obrazu | 5:3 |
| Waga przedmiotu | 1.3 funtów (0.59 kg) |
| Wymiary produktu | 1.02" gł. x 9.64" szer. x 6.42" wys. |
| Baterie | 1 bateria litowo-jonowa (w zestawie) |
| Technologia łączności | HDMI, USB, AV, AC/DC, Antenna Input |
| Cechy specjalne | Portable, Built-in Speaker, Rechargeable Battery, Built-in Digital Tuner, Tabletop Stand |
Gwarancja i wsparcie
For warranty information and customer support, please refer to the documentation included with your product or visit the official Emerson brand store. You can find additional support and product details by visiting the Sklep Emerson na Amazon.
