Schoben Cordless Water Flosser L8 Instruction Manual

Wstęp

The Schoben Cordless Water Flosser L8 is designed to enhance your daily oral hygiene routine. This device utilizes a high-pressure water pulse to effectively remove food debris and plaque from between teeth and below the gumline, areas often missed by traditional brushing and flossing. Regular use can contribute to healthier gums, fresher breath, and a cleaner mouth.

The L8 model features multiple cleaning modes, a large water tank, and a long-lasting rechargeable battery, making it suitable for various oral care needs, including those with braces, implants, or sensitive gums.

Informacje dotyczące bezpieczeństwa

• Always follow instructions for safe use.
• Przechowywać w miejscu niedostępnym dla dzieci.
• Do not use with damaged or broken parts.
• Nie stosować podczas snu lub w stanie nieprzytomności.
• This device is IPX7 waterproof and can be used in the shower. However, ensure the charging port cover is securely closed when exposed to water.
• Nie zanurzaj adaptera ładowania w wodzie.
• Należy używać wyłącznie kabla ładującego dostarczonego przez producenta.
• Do not direct water spray into the eyes, nose, or ears.

Zawartość opakowania

Sprawdź, czy w opakowaniu znajdują się wszystkie elementy:

• Schoben Cordless Water Flosser Unit (L8)
• Standard Nozzle (2x)
• Orthodontic Nozzle (1x)
• Periodontal Nozzle (1x)
• Tongue Cleaner Nozzle (1x)
• Brush Nozzle (1x)
• Kabel ładujący USB
• Torba podróżna
• Instrukcja obsługi

Produkt ponadview

The Schoben L8 Water Flosser showing its main body, control buttons (On/Off, Mode), and the combined toothbrush head attachment.

Illustration of the 360-degree rotatable nozzle feature and the five distinct nozzle types included for comprehensive oral cleaning.

The Schoben L8 features an ergonomic design for comfortable handling. Key components include:

• Nozzle Release Button: Located at the top, press to detach the nozzle.
• Zbiornik na wodę: 300ml capacity, detachable for easy filling and cleaning.
• Przycisk zasilania: Włącza/wyłącza urządzenie.
• Przycisk trybu: Cycles through the four cleaning modes.
• Kontrolki trybu: Display the currently selected mode.
• Port ładowania: USB port, located at the bottom, with a waterproof cover.

Organizować coś

1. Ładowanie początkowe

Before first use, fully charge the device. Connect the USB charging cable to the charging port at the bottom of the unit and plug the other end into a compatible USB power adapter (not included). The indicator lights will show charging status. A full charge takes approximately 3 hours and provides up to 70 days of use.

The water flosser connected to its USB charging cable.

2. Podłączanie dyszy

1. Select the desired nozzle (e.g., Standard, Orthodontic, Brush).
2. Insert the nozzle into the hole at the top of the flosser handle until it clicks into place. Ensure it is firmly seated.
3. To remove, press the nozzle release button and pull the nozzle out.

3. Napełnianie zbiornika na wodę

1. Open the water tank cover located on the side of the unit.
2. Fill the 300ml water tank with lukewarm water. You may also add mouthwash as recommended by your dentist.
3. Close the water tank cover securely to prevent leakage.

Instrukcja obsługi

1. Wybierz tryb: Press the 'M' (Mode) button to cycle through the available cleaning modes: Soft, Normal, Strong, and DIY. Choose the mode that suits your comfort and cleaning needs.
2. Pozycja dyszy: Lean over a sink and place the nozzle tip into your mouth, aiming it at your gumline at a 90-degree angle.
3. Włączanie: Press the On/Off button to start the water flow.
4. Opląt: Guide the water stream along your gumline, pausing briefly between teeth. Allow the water to flow into the sink.
5. Wyczyść wszystkie obszary: Ensure you clean both the front and back surfaces of your teeth, as well as around any dental work like braces or crowns. The 360-degree rotatable nozzle allows for easy access to all areas of your mouth.
6. Wyłączone: Press the On/Off button again to stop the water flow when finished.
7. Pusty zbiornik: After use, empty any remaining water from the tank.

Demonstration of proper technique for using the water flosser for effective cleaning.

Tryby i ustawienia

The Schoben L8 offers four distinct cleaning modes to cater to individual preferences and oral health needs:

• Tryb miękki: Indicated by a green light. Provides a gentle water pressure, ideal for first-time users, individuals with sensitive gums, or those with dental implants.
• Tryb normalny: Indicated by a yellow light. Offers a balanced water pressure for daily cleaning and effective plaque removal.
• Tryb silny: Indicated by a red light. Delivers powerful water pressure for deep cleaning, targeting stubborn food particles and plaque.
• Tryb DIY: Allows you to customize the water pressure from 40 PSI to 120 PSI. Press and hold the mode button to adjust the pressure to your desired level. This mode is suitable for users who require specific pressure settings.

The device operates with a pulse frequency of 1800 times per minute and a water pressure range of 50-140 PSI (depending on the selected mode).

Konserwacja

1. Czyszczenie urządzenia

Przetrzyj zewnętrzną część irygatora miękką, miękką szmatką.amp płótno. Nie używaj ściernych środków czyszczących ani żrących chemikaliów.

2. Czyszczenie zbiornika na wodę

The 300ml water tank is detachable for thorough cleaning. Remove the tank from the main unit and rinse it with warm water. For deeper cleaning, you can use a mild soap and brush. Ensure the tank is completely dry before reattaching.

The detachable water tank of the Schoben L8, illustrating ease of cleaning.

3. Cleaning Nozzles

Rinse nozzles under running water after each use. For optimal hygiene, it is recommended to replace nozzles every 3-6 months, or sooner if they show signs of wear.

4. Przechowywanie

Store the device in a cool, dry place away from direct sunlight. Ensure the water tank is empty before storing for extended periods.

Rozwiązywanie problemów

Specyfikacje

Gwarancja i wsparcie

For warranty information and customer support, please refer to the documentation included with your purchase or contact Schoben customer service directly. Keep your proof of purchase for any warranty claims.
