Graham-Field Lumex HybridLX Rollator & Transport Chair User Manual

Wstęp

The Lumex HybridLX is an innovative 2-in-1 mobility solution designed to function as both a rollator and a transport chair. This versatile device offers users the flexibility to walk independently with support or be comfortably transported when needed. Its lightweight aluminum frame, ergonomic design, and easy conversion mechanism make it suitable for various indoor and outdoor activities. This manual provides essential information for the safe and effective use, assembly, operation, and maintenance of your HybridLX Rollator & Transport Chair.

Informacje dotyczące bezpieczeństwa

WARNING: Failure to follow these instructions may result in serious injury or damage to the product.

• Always ensure all locking mechanisms are engaged before use, whether in rollator or transport chair mode.
• Nie przekraczać maksymalnego udźwigu wynoszącego 136 kg (300 funtów).
• When using as a rollator, ensure the brakes are functioning correctly and engage the parking brakes when standing or sitting.
• When using as a transport chair, ensure the footrests are properly installed and the user is securely seated. An attendant must always be present to push the chair.
• Avoid using the product on uneven surfaces, steep inclines, or stairs.
• Regularly inspect the product for any signs of wear, damage, or loose components. Do not use if damaged.
• Podczas składania i rozkładania trzymaj dłonie i palce z dala od ruchomych części.

Konfiguracja i montaż

Follow these steps to set up your Lumex HybridLX Rollator & Transport Chair:

1. Rozłóż Rollator: Carefully unfold the rollator until it is fully open and stable. Ensure all frame components are securely locked into place.
2. Attach Removable Footrests (Optional): If using as a transport chair, attach the removable footrests to the designated slots on the front frame. Ensure they click securely into position.
3. Dostosuj wysokość uchwytu: Press the push-button on the handle tubes and slide the handles up or down to your desired height. Release the button to lock the handles in place. Ensure both handles are at the same height for balanced support.
4. Familiarize with Handbrakes: Test the handbrakes. Squeeze the levers to slow down or stop. Push the levers down to engage the parking brakes for stationary use.

Obraz: Strona view of the Lumex HybridLX Rollator in its walking configuration, showing the handles and seat.

Obraz: Strona view of the Lumex HybridLX converted into a transport chair, with footrests extended for a seated user.

Obraz: Close-up of the ergonomic handgrips and handbrakes, designed for comfortable and secure operation.

Instrukcja obsługi

Using as a Rollator:

1. Ensure the unit is in rollator mode with footrests removed or folded away.
2. Hold the ergonomic handgrips firmly and push the rollator forward to move.
3. Use the handbrakes to control speed and stop. Engage the parking brakes when standing still or sitting on the mesh seat.

Obraz: A user walking with the HybridLX in rollator mode, demonstrating its use for mobility support.

Converting to a Transport Chair:

1. Zaciągnij hamulec postojowy.
2. If not already attached, install the footrests.
3. Lower the backrest to the transport chair position.
4. Have the user sit comfortably on the 18-inch wide mesh seat.
5. An attendant must push the transport chair using the handles.

Obraz: A user seated in the HybridLX transport chair, being assisted by an attendant.

Folding for Transport and Storage:

1. Ensure the unit is empty and no one is seated.
2. Lift the pull-up strap located on the center of the seat. The unit will begin to fold inward.
3. Continue to fold until compact. You may remove footrests for an even more compact size.
4. Secure the folded unit for transport or storage.

Obraz: The HybridLX being folded using the convenient pull-up strap on the seat.

Konserwacja

Proper maintenance ensures the longevity and safe operation of your HybridLX:

• Czyszczenie: Przetrzyj ramę i siedzisko reklamąamp cloth and mild detergent. Do not use abrasive cleaners. Ensure the product is dry before storage.
• Kontrola kół: Regularly check the wheels for wear, damage, or debris. Clean any hair or lint from the wheel axles.
• Kontrola hamulców: Periodically test the handbrakes to ensure they engage smoothly and effectively. Adjust if necessary (refer to a qualified technician if unsure).
• Elementy złączne: Check all screws, bolts, and other fasteners regularly to ensure they are tight. Do not overtighten.
• Składowanie: Store the product in a dry, clean environment away from extreme temperatures.

Rozwiązywanie problemów

If you encounter issues with your HybridLX, refer to the following common solutions:

• Stopień trudności składania/rozkładania: Ensure no obstructions are present. Check that the seat strap is pulled firmly and evenly.
• Hamulce nie działają: Inspect the brake cables for damage or looseness. Ensure the brake levers are fully depressed or squeezed. If issues persist, professional adjustment may be required.
• Niestabilna praca: Verify that all frame components are fully extended and locked. Check that the handle height adjustment pins are securely engaged.
• Squeaking Wheels: Clean wheels and axles. A small amount of silicone-based lubricant can be applied to moving parts, avoiding brake surfaces.

For problems not listed here or if solutions do not resolve the issue, contact Graham-Field customer support.

Specyfikacje

Gwarancja i wsparcie

For warranty information, please refer to the documentation included with your product or visit the official Graham-Field website. For technical support, replacement parts, or any inquiries not covered in this manual, please contact Graham-Field customer service directly.

Producent: Produkty zdrowotne GF, Inc.

Webstrona: www.grahamfield.com
